Job Card D/R A210 - Gantry cover replacement guide
Page no. 1201 Chapter 9
JC-DR-A-210.fm
3-3-1 Column Covers - non-available covers
• If the reference of the defective part appears in the following table, it cannot be replaced individually.
A complete set of covers must be ordered and installed:
- Order a set of covers as listed below:
- Install the new covers using the information given in Job Card PHY A044 - Remove/Reinstall
Gantry Covers, section 7 page 524.
3-3-2 Column Covers - available covers
• If the reference of the defective part appears in the following table, it can be replaced individually.
The table indicates the necessary part(s) to be ordered.
- Install the new cover(s) using the information given in Job Card PHY A044 - Remove/Reinstall
Gantry Covers, section 7 page 524.
Reference Description
2375027 2375027-3 Column Cover Top Left
2375028 2375028-3 Column Cover Top Right
2375029 2375029-3 Column Cover Cable Exit
2375030 2375030-3 Column Cover Bottom Front
2375031 2375031-3 Column Cover Bottom Back
2375032 2375032-3 Column Cover Front Left
2375033 2375033-3 Column Cover Front Right
Reference Description Quantity
2375027-2 Column Cover Top Left 1
2375028-2 Column Cover Top Right 1
2375029-2 Column Cover Cable Exit 1
2375030-2 Column Cover Bottom Front 1
2375031-2 Column Cover Bottom Back 1
2375032-2 Column Cover Front Left 1
2375033-2 Column Cover Front Right 1
5130589 Kit of screws and caps for covers 1
If the defective part is:
Order the following parts:
Reference Description Quantity
2375027-2 Column Cover Top Left 2375027-2 Column Cover Top Left 1
2375028-2 Column Cover Top Right 2375028-2 Column Cover Top Right 1
2375029-2 Column Cover Cable Exit 2375029-2 Column Cover Cable Exit 1
2375030-2 Column Cover Bottom Front 2375030-2 Column Cover Bottom Front 1
2375031-2 Column Cover Bottom Back 2375031-2 Column Cover Bottom Back 1
2375032-2 Column Cover Front Left 2375032-2 Column Cover Front Left 1
2375033-2 Column Cover Front Right 2375033-2 Column Cover Front Right 1
Order also: 5130589 Kit of screws and caps for covers 1
