Chapter 9 Page no. 1338
JC-DR-A-252.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job card D/R A252 - Compression Trolley Kit
7 COMPLETION
• Check compression motion and keypad.
• Carry out the following calibration procedures: :
Calibrations - Checks Job Card
Gantry
Compression Force Sensor Job Card CAL A048 - Calibration of Compression Force Sensor on page
1709
Compression Thickness Job Card CAL A050 - Compression Thickness Calibration on page 1721
If Compression Thickness not OK, repeat calibrations from Compression Force Sensor
AOP/SNR Check Job Card ELE A038 - AOP Mode and SNR Check on page 707
If AOP/SNR Test not OK, repeat all calibrations
