Chapter 9 Page no. 1522
JC-DR-A-331.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A331 - UPS
Note:
Note locations of disconnected cables.
3. Disconnect the ground cable (small screwdriver) located at the top of the UPS rear panel.
4. Remove the four screws (2) (two on both side - 5 mm allen wrench) securing the UPS to the Control
Station.
5. Remove the defective UPS unit from the Control Station.
2
2
To Next Page
