Chapter 9 Page no. 1536
JC-DR-A-332.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A332 - UPS Battery Replacement
The following table lists the indicators and features with their respective descriptions / functions.
Indicator Description
Onlin The UPS is supplying utility power to the connected
equipment.
AVR Trim The UPS is compensating for a high utility voltage.
AVR Boost The UPS is compensating for a low utility voltage.
On Battery The UPS is supplying battery power to the connected
equipment.
Overload The connected loads are drawing more than the UPS
power rating.
Replace Battery / Battery Disconnected The battery is disconnected or must be replaced.
Power On Press this button to turn on the UPS. (Read on for addi-
tional capabilities.)
Power Off Press this button to turn off the UPS.
