GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card CAL A043 - Detector Gain Calibration
Page no. 1699 Chapter 9
JC-CAL-A-043.fm
7-4 If Stereotaxy Option Present
7-4-1 Prerequisites
The Stereotaxy option should have been installed and calibrated and plugged-in before performing these
six additional gain calibrations.
7-4-2 Calibrations
Six more calibrations are needed if the Stereotaxy option is present:
If the Stereotix option is present, perform the following steps before running the Detector Gain Calibra-
tion:
a. Plug the stereotix on the system
b. Perform an angulation to reach -15°
c. Remove the stereotix
d. Launch the first -15° gain configuration
e. Perform the exposures for -15° maps as written on the screen
f. Perform the other -15° configurations
g. Plug the stereotix on the system again
h. Perform the angulation to reach +15°
i. Remove the stereotix
j. Perform the 3 gain maps at 15°
k. When all the stereo gain maps are calibrated, move back to the 0° position.
l. It is now safe to exit the calibrations.
Technique for calibration IQ check technique;
Calibration technique
Configuration
Mo/Mo/LF/nogrid/-15° Mo/Mo 26 kV 32 mAs, LF;
Mo/Mo 26 kV 160 mAs, LF
No Bucky, no paddle.
Phantom on image receptor.
Arm at -15°
Mo/Rh/LF/nogrid/-15° Mo/Rh 28 kV 18 mAs, LF;
Mo/Rh 28 kV 90 mAs, LF
No Bucky, no paddle.
Phantom on image receptor.
Arm at -15°
Rh/Rh/LF/nogrid/-15° Rh/Rh 30 kV 11 mAs, LF;
Rh/Rh 30 kV 56 mAs, LF
No Bucky, no paddle.
Phantom on image receptor.
Arm at -15°
Mo/Mo/LF/nogrid/15° Mo/Mo 26 kV 32 mAs, LF;
Mo/Mo 26 kV 160 mAs, LF
No Bucky, no paddle.
Phantom on image receptor.
Arm at 15°
Mo/Rh/LF/nogrid/15° Mo/Rh 28 kV 18 mAs, LF;
Mo/Rh 28 kV 90 mAs, LF
No Bucky, no paddle.
Phantom on image receptor.
Arm at 15°
Rh/Rh/LF/nogrid/15° Rh/Rh 30 kV 11 mAs, LF;
Rh/Rh 30 kV 56 mAs, LF
No Bucky, no paddle.
Phantom on image receptor.
Arm at 15°
