Page no. 171 Chapter 3
Component-index.fm GE Healthcare Senographe DS Revision 1 Service Information and Procedures Class A 2385072-16-8EN
FRU/Component Index - Gantry
75 Belt-Compr-Manual-600mm
10mm
2388175 Loc
page
193
FRU Y Trac N D/R
page
1299
75 Belt-Compr-Motorized-225mm
9mm
2374629 Loc
page
194
FRU Y Trac N D/R
page
1297
75 Belt -Guiding, Lower 2410101 FRU Y
75 Belt -Guiding, Upper 2410102 FRU Y
75 Belt-Lift 1830mm 25mm 2363778-1 Loc
page
191
FRU Y Trac N D/R
page
1189
75 Belt-Rotation-294mm 15mm 2260269-2 Loc
page
191
FRU Y Trac N
75 Cable tie-Compression D70/
L250x4.8
2387733-5 FRU Y Trac N
75 Lift Screw Assembly (Type 2 or
Type 3)
See Supplies on
page 1255
Loc
page
192
FRU Y Trac N D/R
page
1255
75 Lift Screw Assembly Top Brake
(Type 2 Lift Screw Assemblies
only)
5198687 FRU Y Trac N D/R
page
1279
75 Chain Energy-Compr 2388037 Loc
page
194
FRU Y Trac N
75 Clamp-Tube 46-208713P1 FRU Y P-D/R
page
825
75 Cover-Detector Upper. To
replace 2375024 or 2375024-3
see J.C. D/R A210 on page 1197.
2375024-2 Loc
page
189
FRU Y D/R
page
523
75 Cover-Detector Lower. To
replace 2375025 or 2375025-3
see J.C. D/R A210 on page 1197.
2375025-2 Loc
page
189
FRU Y D/R
page
523
Class Component Description Reference Comp. Loc FD Cabl CL FRU Trac D/R
