Job Card CAL A049 - Compression Paddle Offset Calibration
TABLE 2 - COMPRESSION PADDLE OFFSETS
Paddle
Number
Compression Paddle Name
(Ref. Number on Label)
A
Existing Offset in
displayed in
1/10th of a mm
B
Known Thickness
in 1/10th of a mm
C
Calculated
Offset in
1/10th of a mm
D
Final Offset to declare
in 1/10th of a mm
(i.e. value from Col-
umn A + value from
column C)
1 Flexible 19x23
(2383182-2)
2 Standard 19x23
(2373344)
3 Axillary
(2373360)
4 Round spot
(2373347)
5 Square spot
(2373343)
6 2D Large localization paddle
DS : (2373385)
Essential : (5172704)
7 2D Spot localization paddle
DS : (2373389)
Essential : (5172624)
11 High wall
(Not yet available, future use)
12 19 x 23 magnification paddle
DS : (2397559)
Essential : (5172828)
14 Round spot magnification
paddle
DS : (2397557)
Essential : (5172946)
15 7 x 7 square magnification
paddle
DS : (2397558)
Essential : (5172686)
