Job Card CHK A011 - Check kVp settings
9 PROCEDURE - KEITHLEY 35080B KVP METER
!
Notice:
This meter is not recommended for use in Europe; it does not meet the European accuracy require-
ment of 3%.
9-1 kVp meter calibration
• Note the meter identification number and date of most recent calibration:
9-2 Position the meter
1. Ensure that the Radiation Protection Plate is 205 mm (8.07 inches) below the bottom of the Tube
Head.
2. Place the kV peak meter on the Radiation Protection Plate located on the Standard 19 x 23 Com-
pression Paddle.
3. Use the Senographe light centering device to center the kV peak meter target with the X-ray zone.
kVp meter
identification number
Date of calibration:
(dd/mm/yy)
