Location-Gantry_DS.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
3-1-9. MPCB - PDU Board
Cable W107
Cable W104
Stop Motion
Left
Cable W101
Cable W315
PDU Board
PL101
Fuses F1,
F3, F4
Cable W209
Cable W111
Fuses F5, F6
Cable W125
Cable W110
