GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
Page no. 259 Chapter 3
Indicators and Switches.fm
2-4-1. Inverter Board 300PL1 Connectors
Connector Function
XJ1 To the XJ7 connector on the Generator Command Board 400PL1 (Prep, Exposure thyristor
command)
X1 0V/600VR
X2 Not Applicable
X3 415 V Monophase (1)
X4 415 V Monophase (2)
X5 600VR
X6 300VR
X7 600VF
X8 HF2
X9 HF1
X10 0V/600VF
X11 Thermal Switch (1)
X12 Thermal Switch (2)
X13 Gate/TH1
X14 K / TH1
X15 Gate/TH2
X16 K / TH2
