Chapter 3 Page no. 268
Indicators and Switches.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
2-6-3. Mains Distribution Board 200PL1 Neon Lights
2-6-4. Mains Distribution Board 200PL1 Fuses
2-6-5. Mains Distribution Board 200PL1 Potentiometers
2-6-6. Mains Distribution Board 200PL1 Straps
2-6-7. Mains Distribution Board 200PL1 Switches
LED Function Color Behavior
N1 Power Present Orange Normal status: ON
ON when power from the Generator Transformer is
present.
OFF when power from the Generator Transformer
is not present. In this case check the status of the
N2 neon light.
N2 K1 under tension Orange Normal status: ON
ON when the K1 contact is under tension.
OFF when the K1 contact is not under tension. In
this case, proceed as follows:
• Check the X2 relay on the Mains Distribution
Board 200PL1.
• If the X2 relay is okay, check that the tension
selector (SEL) is on the correct value.
• If the X2 relay and the tension selector are OK,
check the upstream fuses at the mains input.
Fuse Specification PN Function
F1 250 Vac, 1 A, Delay 58079686 1 A/250 V (+8 V)
F2 250 Vac, 0.5 A, Delay 58079685 0.5 A/250 V (-8 V)
F3 0.5 A/250 V (+12 V)
Strap Function
P1 Threshold E_Sup_EMax_a
P2 Threshold E_Sup_EMin_a
Strap Function
IN1 Not Applicable
IN2 BT Power Selector. Must be on left-hand side in the BT position.
Strap Function
SW1 Test measure E
SW2 Test measure E
