10-3-2-2. Anchoring Inserts Not Provided with the Senographe System (for seismic areas)
The following tables provide the recommended anchoring inserts seismic areas. Due to the differing
availability of Hilti bolts in different contentinents, the following tables provide different bolt recommenda-
tions. The minimum floor thickness required varies according to the bolts used.
USA - Hilti Kwick Bolt III
EUROPE - Hilti HSA Bolts
Anchoring holes in the floor Gantry baseplate
(see Illustration 15)
Gantry baseplate addi-
tional anchoring holes for
seismic areas
(see Illustration 15)
Control station base-
plate
(see Illustration 16)
Number of holes in the plate 324
Diameter of the hole in the
plate
11 mm 11 mm 14 mm
Recommended inserts Hilti Kwik Bolt III 3/8" Hilti Kwik Bolt III 3/8" Hilti Kwik Bolt III 3/8"
Hole diameter in the floor 9.5 mm (3/8”) 9.5 mm (3/8”) 9.5 mm (3/8”)
Hole depth in the floor 64 mm (2 ½”) 64 mm (2 ½”) 64 mm (2 ½”)
Minimum floor thickness 95 mm (3 ¾”) 95 mm (3 ¾”) 95 mm (3 ¾”)
Maximum bolt load pull ten-
sion (at each bolt)
490 daN 490 daN 490 daN
Recommended tightening
torque
34 Nm 34 Nm 34 Nm
Anchoring holes in the floor Gantry baseplate
(see Illustration 15)
Gantry baseplate addi-
tional anchoring holes for
seismic areas
(see Illustration 15)
Control station base-
plate
(see Illustration 16)
Number of holes in the plate 324
Diameter of the hole in the
plate
11 mm 11 mm 14 mm
Recommended inserts HSA M10 x 90 - 20 / 25 HSA M10 x 90 - 20 / 25 HSA M10 x 90 - 20 / 25
Hole diameter in the floor 10 mm 10 mm 10 mm
Hole depth in the floor 70 mm 70 mm 70 mm
Maximum bolt load pull ten-
sion (at each bolt)
490 daN 490 daN 490 daN
Minimum floor thickness 105 mm 105 mm 105 mm
Recommended tightening
torque
34 Nm 34 Nm 34 Nm
