GE Senographe DS User Manual

Chapter 6 Page no. 476
JC-PHY-A-018.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card PHY A018 - Room Lamps and Door Configuration
3. Locate board 400-PL1. Refer illustration 3; and set jumpers JP1 and JP2 as required according to the
table below. Place unused jumpers in the parking positions JP3 and JP4.
Note:
If there is no door switch, jumpers JP1 and JP2 must both be present (case 4 in the table).
TABLE 1 - JP1 AND JP2 JUMPER SETTINGS
0 = No jumper
1 = Jumper present
Note:
When the room door switch is present and configured for use, the signals valid-PR (first trigger or
prep) and valid-GR (RADIOGRAPHY) are enabled through the switch.
JP1
(RADIOGRAPHY)
JP2
(PREP)
Door closed Door opened
1 0 0 PREP and RADIOGRAPHY
enabled
PREP and RADIOGRAPHY
disabled
2 1 0 PREP and RADIOGRAPHY
enabled
PREP and RADIOGRAPHY
disabled.
NOTE:
if the door opens during
an exposure, the exposure is not
aborted and completes normally
)
3 0 1 PREP and RADIOGRAPHY
enabled
PREP enabled
RADIOGRAPHY disabled
4 1 1 PREP and RADIOGRAPHY
enabled
PREP and RADIOGRAPHY
enabled
