GE Senographe DS

GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
Page no. 859 Chapter 9
ERR-SUB-A-003.fm
102/025 HALT LIFT RELATIVE
ENCODER ERROR
Possible causes:
• There is a relative encoder error. The signal com-
ing from the relative encoder does not evolves dur-
ing the motion while the signal coming from the
absolute encoder does.
• This error can be also due to a mechanical play of
the lift screw; or because the gas spring could have
failed.
Proceed as follows:
1. Change the Lift Motor + Encoder + Cable (see
Job Card D/R A205 - Lift Motor on page 1179).
2. If the problem persists, change the Lift Potenti-
ometer + Cable (see Job Card D/R A204 - Lift
Potentiometer on page 1175).
3. If the problem persists, change the Lift Gas
Spring (Job Card D/R A206A - Lift Gas Spring on
page 1183).
D/R A205
page
1179
D/R A204
page
1175
D/R
A206A
page
1183
102/026 HALT LIFT ABSOLUTE
ENCODER ERROR
The lift potentiometer is faulty and generating too
much noise.
Change the Lift Potentiometer and Cable (see Job
Card D/R A204 - Lift Potentiometer on page 1175)
D/R A204
page
1175
102/027 WARNING LIFT MCU CALI-
BRATION DATA
CORRUPT
The MCU calibration data is corrupt. The checksum
on the calibration data stored by the MCU does not
match.
Perform a Lift calibration.
If the problem persists, change the lift board.
CAL A031
page
1687
D/R A201
page
1161
102/028 WARNING LIFT DSP CALIBRA-
TION DATA COR-
RUPT
The DSP calibration data is corrupt. The checksum
on the calibration data stored by the DSP does not
match.
Perform a Lift calibration.
If the problem persists, change the lift board.
CAL A031
page
1687
D/R A201
page
1161
102/029 HALT LIFT MCU EEPROM
FAILURE
There has been an MCU EEPROM failure. The read-
back on the newly written data to the EEPROM has
failed.
Change the Lift board then perform Lift Calibration.
D/R A201
page
1161
CAL A031
page
1687
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
