GE Senographe DS

Chapter 9 Page no. 870
ERR-SUB-A-003.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
112/020 HALT LOW VOLTAGE
ERROR ON ROTA-
TION NODE
There is a low voltage error. Occurs if the voltage of
the power supply to the rotation board falls below
24 V.
Change the Rotation board then perform Rotation
Calibration.
D/R A221
page
1223
CAL A021
page
1679
112/021 HALT ROTATION READ
TIMEOUT ERROR
There is a read timeout error. Occurs if the MCU
does not react within 15 ms of receiving an interrupt
request (IRQ) coming from the CPLD.
Change the Rotation board then perform Rotation
Calibration.
D/R A221
page
1223
CAL A021
page
1679
112/022 HALT ROTATION CPLD
MEMORY ERROR
There is a CPLD memory error. Test data from the
CPLD is periodically read to ensure the proper com-
munication. If this error does not match the node
sends this error.
Change the Rotation board then perform Rotation
Calibration.
D/R A221
page
1223
CAL A021
page
1679
112/023 HALT UNCONTROLLED
ROTATION
MOTION
DETECTED. STOP
LINE ACTIVATED
There is uncontrolled motion. If the motion is per-
formed when the rotation node is not supposed to
drive it, the rotation node sends this error, and acti-
vates the MCU_STOP_MOTION line which leads to
0x500A error.
Change the rotation gas spring (Job Card D/R A230
- Rotation Gas Spring on page 1251).
D/R A230
page
1251
112/024 HALT ROTATION RELA-
TIVE ENCODER
ERROR
There is a relative encoder error. Occurs when the
signal coming from the relative encoder does not
evolve during the rotation motion while the signal
coming from the absolute encoder does.
Change the Rotation Motor + Encoder + Cables
W205 and W302 (see Job Card D/R A228 - Rotation
Motor on page 1243).
D/R A228
page
1243
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
