1-9. The DISP Parameter
• The DISP (display) parameter is provided to aid service procedures; it controls the display of certain
parameters after an exposure. When it is set to YES, the two groups of exposure parameters shown
in the table below are displayed alternately
:
Composition Breast composition
Thickness: Breast thickness in equivalent cm of acrylic.
Prep dose: Dose for pre-shot (returned by IDC)
Prep kV: kV used for pre-shot
Prep track: Track used for pre-shot
Prep filter: Filter used for pre-shot
Delta grid: Delta time (ms) from end of X-ray emission to grid U-turn
To change the DISP parameter, access SETUP/GENE/INSTAL/GENE/CONFIG/DISP, and select YES
or NO. A CKSUM is NOT necessary because this parameter is not a saved parameter. When power is
turned off, the value of DISP is lost and reverts to NO at the next power-up.
Group 1: kV mAs mA Time Ih
Group 2: Composition Thickness Prep dose Prep kV Prep track Prep filter Delta grid
