HEIDENHAIN iTNC 530 683
18.3 Technical Information
Software option 1
Rotary table machining îš‹Programming of cylindrical contours as if in two axes
îš‹Feed rate in distance per minute
Coordinate transformation îš‹Tilting the working plane
Interpolation îš‹Circle in 3 axes with tilted working plane
Software option 2
3-D machining z Motion control with minimum jerk
z 3-D tool compensation through surface normal vectors
z Using the electronic handwheel to change the angle of the swivel head during program
run without affecting the position of the tool point (TCPM = Tool Center Point
Management)
z Keeping the tool normal to the contour
z Tool radius compensation normal to the direction of traverse and the tool direction
z Spline interpolation
Interpolation z Linear in 5 axes (subject to export permit)
Block processing time z 0.5 ms
DXF Converter software option
Extracting contour programs
and machining positions from
DXF data
îš„ Format supported: AC1009 (AutoCAD R12)
îš„ For plain-language and smarT.NC
îš„ Simple and convenient specification of reference points
Dynamic Collision Monitoring (DCM) software option
Collision monitoring in all
machine operating modes
îš„ The machine manufacturer defines objects to be monitored
îš„ Fixture monitoring is also possible
îš„ Three warning levels in manual operation
îš„ Program interrupt during automatic operation
îš„ Includes monitoring of 5-axis movements
îš„ Program simulation before machining for possible collisions
Additional conversational language software option
Additional conversational
languages
îš„ Slovenian
îš„ Norwegian
îš„ Slovak
îš„ Latvian
îš„ Korean
îš„ Estonian
îš„ Turkish
îš„ Romanian
îš„ Lithuanian
