138 Programming: Fundamentals, File Management

3.4 Working with the file manager

Tagging files

Tagging function Soft key

Move cursor upward

Move cursor downward

Tag a single file

Tag all files in the directory

Untag a single file

Untag all files

Copy all tagged files
