11.1 Overview of special functions

Programming aids menu

 Select the programming aids menu

 Select the menu for file conversion

Function Soft key Description

Structured program conversion

from FK to H

Page 257

Unstructured program

conversion from FK to H

Page 257

Generate a backward program Page 452

Filter contours Page 455
