580 Manual Operation and Setup

14.3 Spindle speed S, feed rate F and miscellaneous functions M

Changing the spindle speed and feed rate

With the override knobs you can vary the spindle speed S and feed

rate F from 0% to 150% of the set value.

The override knob for spindle speed is only functional on

machines with infinitely variable spindle drive.
