684 MOD Functions

17.9 Showing the workpiece blank in the working space

Rotating the entire image

The third soft-key row provides functions with which you can rotate

and tilt the entire image:

Function Soft keys

Rotate the image about the vertical axis

Tilt the image about the horizontal axis
