16.7 Optional program-run interruption

16.7 Optional program-run

interruption

Application

The TNC optionally interrupts program run at blocks containing M1. If

you use M1 in the Program Run mode, the TNC does not switch off the

spindle or coolant, if necessary. Your machine tool manual provides

more information.

 Do not interrupt Program Run or Test Run at blocks

containing M1: Set the soft key to OFF

 Interrupt Program Run or Test Run at blocks

containing M1: Set the soft key to ON

M1 is not effective in the Test Run mode of operation.
