HEIDENHAIN iTNC 530 73

1.6 Workpiece setup

Selecting the correct operating mode

Workpieces are set up in the Manual Operation or Electronic

Handwheel mode

 Press the Manual Operation operating mode key: the

TNC switches to that mode

Further information on this topic

 Manual Operation mode: See "Moving the machine axes", page 567

Clamping the workpiece

Mount the workpiece with a fixture on the machine table. If you have

a touch probe on your machine, then you do not need to clamp the

workpiece parallel to the axes.

If you do not have a touch probe available, you have to align the

workpiece so that it is fixed with its edges parallel to the machine

axes.
