HEIDENHAIN iTNC 530 403

11.1 Overview of special functions

Program defaults menu

 Select the program defaults menu

Functions for contour and point machining

 Select the menu for functions for contour and point

machining

Function Soft key Description

Workpiece blank definition Page 108

Define the material Page 470

Define global cycle parameters See User's

Manual for Cycles

Select datum table See User's

Manual for Cycles

Load fixture Page 421

Reset fixture Page 421

Function Soft key Description

Define a simple contour formula See User's

Manual for Cycles

Call the menu for complex

contour formula

See User's

Manual for Cycles

Define regular machining pattern See User's

Manual for Cycles

Select the point file with

machining positions

See User's

Manual for Cycles
