HEIDENHAIN iTNC 530 157

4.1 Adding comments

Functions for editing of the comment

Function Soft key

Jump to beginning of comment

Jump to end of comment

Jump to the beginning of a word. Words must be

separated by a space

Jump to the end of a word. Words must be

separated by a space

Switch between insert mode and overwrite

mode
