HEIDENHAIN iTNC 530 567

14.2 Moving the machine axes

Note

Moving the axis using the machine axis direction

buttons

Select Manual operating mode

Press the machine axis direction button and hold it as

long as you wish the axis to move, or

Move the axis continuously: Press and hold the

machine axis direction button, then press the

machine START button

To stop the axis, press the machine STOP button

You can move several axes at a time with these two methods. You can

change the feed rate at which the axes are traversed with the F soft

key, see "Spindle speed S, feed rate F and miscellaneous functions M",

page 579.

Traversing with the machine axis direction buttons can

vary depending on the machine tool. The machine manual

provides further information.
