56 First Steps with the iTNC 530

1.1 Overview

This chapter is intended to help TNC beginners quickly learn to handle

the most important procedures. For more information on a respective

topic, see the section referred to in the text.

The following topics are included in this chapter:

 Machine switch-on

 Programming the first part

 Graphically testing the first part

 Setting up tools

 Workpiece setup

 Running the first program
