404 Programming: Special Functions

11.1 Overview of special functions

Functions for contour and point machining

 Select the menu for functions for contour and point

machining

Menu of various conversational functions

 Select the menu for defining various plain-language

functions

Function Soft key Description

Select a contour definition See User's

Manual for Cycles

Assign contour description See User's

Manual for Cycles

Define a complex contour

formula

See User's

Manual for Cycles

Function Soft key Description

Define the positioning behavior

for rotary axes

Page 514

Define file functions Page 456

Define program call Page 460

Define coordinate

transformations

Page 457

Define string functions Page 353
