582 Manual Operation and Setup

14.4 Functional safety FS (option)

Explanation of terms

Safety-related operating modes:

Safety functions

Designation Short description

SOM_1 Safe operating mode 1: Automatic operation,

production mode

SOM_2 Safe operating mode 2: Set-up mode

SOM_3 Safe operating mode 3: Manual intervention;

only for qualified operators

SOM_4 Safe operating mode 4: Advanced manual

intervention, process monitoring

Designation Short description

SS0, SS1, SS1F,

SS2

Safe stop: safe stopping of all drives using

different methods

STO Safe torque off: energy supply to the motor is

interrupted. Provides protection against

unexpected start of the drives

SOS Safe operating stop. Provides protection

against unexpected start of the drives

SLS Safely-limited speed. Prevents the drives

from exceeding the specified speed limits

when the protective door is opened
