13.2 Pallet operation with tool-oriented machining
 If the entries TO or CTO for all workpieces within a group contain the
status ENDED, the next lines in the pallet file are run.
Exiting the pallet file
 Call the file manager: Press the PGM MGT key
 To select a different type of file, press the SELECT TYPE soft key
and the soft key for the desired file type, for example SHOW .H
 Select the desired file
Executing a pallet file
 Select the file manager in the Program Run, Full Sequence or
Program Run, Single Block operating modes: Press the PGM MGT
key
 Display all type .P files: Press the SELECT TYPE and SHOW .P soft
keys
 Select the pallet table with the arrow keys and confirm with ENT
 To execute the pallet table: Press the NC Start button. The TNC
executes the pallets as set in MP7683.
In mid-program startup, only one tool-oriented machining
operation is possible. Subsequent pieces are machined
according to the method entered.
The value entered in the CT-ID field is stored for a
maximum of 2 weeks. Within this time the machining
process can be continued at the stored location. After this
time the value is deleted, in order to prevent large
amounts of unnecessary data on the hard disk.
The operating mode can be changed after executing a
group of entries with TO or CTO.
The following functions are not permitted:
 Switching the traverse range
 PLC datum shift
 M118
In MP7683, set whether the pallet table is to be executed
blockwise or continuously (see "General user parameters"
on page 704).
Provided that Machine Parameter 7246 is set so that the
tool usage test is active, you can monitor the tool service
life for all tools used in a pallet (see "Tool usage test" on
page 202).
