17.8 Machine-specific user parameters

17.8 Machine-specific user

parameters

Application

To enable you to set machine-specific functions, your machine tool

builder can define up to 16 machine parameters as user parameters.

This function is not available on all TNCs. Refer to your

machine manual.
