688 MOD Functions

17.13 Selecting the axes for generating L blocks

17.13 Selecting the axes for

generating L blocks

Application

The axis selection input field enables you to define the current tool

position coordinates that are transferred to the L block To generate a

separate L block, press the ACTUAL POSITION CAPTURE key. The

axes are selected by bit-oriented definition similar to programming the

machine parameters:

Axis selection %11111: Transfer the X, Y, Z, IV, and V axes

Axis selection %01111: X, Y, Z, IV. Transfer the axis

Axis selection %00111: Transfer the X, Y and Z axes

Axis selection %00011: Transfer the X and Y axes

Axis selection %00001: Transfer the X axis
