2.4 Status displays
Additional status displays
The additional status displays contain detailed information on the
program run. They can be called in all operating modes except for the
Programming and Editing mode of operation.
To switch on the additional status display:
Call the soft-key row for screen layout
Select the screen layout with additional status
display: In the right half of the screen, the TNC shows
the Overview status form
To select an additional status display:
Switch the soft-key rows until the STATUS soft keys
appear
Either select the additional status display directly by
soft key, e.g. positions and coordinates, or
use the switch-over soft keys to select the desired
view
The available status displays described below can be selected either
directly by soft key or with the switch-over soft keys.
Please note that some of the status information described
below is not available unless the associated software
option is enabled on your TNC.
