HEIDENHAIN iTNC 530 365

9.11 Preassigned Q parameters

Tool axis: Q109

The value of Q109 depends on the current tool axis:

Spindle status: Q110

The value of the parameter Q110 depends on the M function last

programmed for the spindle.

Coolant on/off: Q111

Overlap factor: Q112

The overlap factor for pocket milling (MP7430) is assigned to Q112.

Tool axis Parameter value

No tool axis defined Q109 = –1

in X axis Q109 = 0

Y axis Q109 = 1

Z axis Q109 = 2

U axis Q109 = 6

5th axis Q109 = 7

W axis Q109 = 8

M function Parameter value

No spindle status defined Q110 = –1

M3: Spindle ON, clockwise Q110 = 0

M4: Spindle ON, counterclockwise Q110 = 1

M5 after M3 Q110 = 2

M5 after M4 Q110 = 3

M function Parameter value

M8: Coolant ON Q111 = 1

M9: Coolant OFF Q111 = 0
