18.2 Pin layouts and connecting cables for the data interfaces
When using the 9-pin adapter block:
Non-HEIDENHAIN devices
The connector layout of a non-HEIDENHAIN device may substantially
differ from that of a HEIDENHAIN device.
It depends on the unit and the type of data transfer. The table below
shows the connector pin layout on the adapter block.
TNC Connecting cable 355484-xx
Adapter block
363987-02
Connecting cable 366964-xx
Male Assignment Female Color Male Female Male Female Color Female
1 Do not use 1 Red 1 1 1 1 Red 1
2 RXD 2 Yellow 2 2 2 2 Yellow 3
3TXD 3 White 3 3 33 White 2
4 DTR 4 Brown 4 4 4 4 Brown 6
5 Signal GND 5 Black 5 5 5 5 Black 5
6 DSR 6 Violet 6 6 6 6 Violet 4
7RTS 7 Gray 7 7 77 Gray 8
8 CTS 8 White/Green 8 8 8 8 White/Green 7
9 Do not use 9 Green 9 9 9 9 Green 9
Hsg. External shield Hsg. External shield Hsg. Hsg. Hsg. Hsg. External shield Hsg.
Adapter block 363987-02 Connecting cable 366964-xx
Female Male Female Color Female
111Red1
2 2 2 Yellow 3
333White2
4 4 4 Brown 6
5 5 5 Black 5
666Violet4
777Gray8
8 8 8 White/Green 7
9 9 9 Green 9
Hsg. Hsg. Hsg. External
shield
Hsg.
