176 Programming: Programming Aids

4.8 The context-sensitive help system TNCguide (FCL3 function)

Chinese (simplified) TNC:\tncguide\zh

Chinese (traditional) TNC:\tncguide\zh-tw

Slovenian (software option) TNC:\tncguide\sl

Norwegian TNC:\tncguide\no

Slovak TNC:\tncguide\sk

Latvian TNC:\tncguide\lv

Korean TNC:\tncguide\kr

Estonian TNC:\tncguide\et

Turkish TNC:\tncguide\tr

Romanian TNC:\tncguide\ro

Lithuanian TNC:\tncguide\lt

Language TNC directory
