HEIDENHAIN iTNC 530 183
5.2 Tool data
DL Delta value for tool length L.
Input range in mm: -999.9999 to +999.9999
Input range in inches: -39.37 to +39.37
Tool length oversize?
DR Delta value for tool radius R.
Input range in mm: -999.9999 to +999.9999
Input range in inches: -39.37 to +39.37
Tool radius oversize?
DR2 Delta value for tool radius R2.
Input range in mm: -999.9999 to +999.9999
Input range in inches: -39.37 to +39.37
Tool radius oversize R2?
LCUTS Tooth length of the tool for Cycle 22.
Input range in mm: 0 to +99999.9999
Input range in inches: 0 to +3936.9999
Tooth length in the tool axis?
ANGLE Maximum plunge angle of the tool for reciprocating plunge-cut in
Cycles 22, 208 and 25x.
Input range: 0 to 90°
Maximum plunge angle?
TL Set tool lock (TL: for Tool Locked).
Input range: L or space character
Tool locked?
Yes = ENT / No = NO ENT
RT Number of a replacement tool, if available (RT: for replacement
tool); see also TIME2).
Input range: 0 to 65535
Replacement tool?
TIME1 Maximum tool life in minutes. This function can vary depending
on the individual machine tool. Your machine manual provides
more information.
Input range: 0 to 9999 minutes
Maximum tool age?
TIME2 Maximum tool life in minutes during a TOOL CALL: If the current
tool age reaches or exceeds this value, the TNC changes the tool
during the next TOOL CALL (see also CUR.TIME).
Input range: 0 to 9999 minutes
Maximum tool age for TOOL CALL?
CUR.TIME Current age of the tool in minutes: The TNC automatically counts
the current tool life (CUR.TIME). A starting value can be entered for
used tools.
Input range: 0 to 99999 minutes
Current tool age?
OVRTIME Maximum amount in minutes that the tool life may be exceeded.
This function can vary depending on the individual machine tool.
Your machine manual provides more information.
Input range: 0 to 99 minutes
Permitted overrun of service life?
Abbr. Inputs Dialog
