HEIDENHAIN iTNC 530 217
5.3 Tool compensation
Entering radius compensation
Radius compensation is entered in an L block. Enter the coordinates
of the target point and confirm your entry with ENT
Select tool movement to the left of the contour: Press
the RL soft key or
Select tool movement to the right of the contour:
Press the RR soft key or
Select tool movement without radius compensation
or cancel radius compensation: Press the ENT key
Terminate the block: Press the END key
RADIUS COMP.: RL/RR/NO COMP.?
