244 Programming: Programming Contours

6.4 Path contours—Cartesian coordinates

15LX+5

Move to last contour point 1

16 DEP LCT X-20 Y-20 R5 F1000

Depart the contour on a circular arc with tangential connection

17 L Z+250 R0 FMAX M2

Retract the tool, end program

18 END PGM CIRCULAR MM
