342 Programming: Q Parameters
9.8 Additional functions
7 - Tilted working plane active / inactive (value not
equal to 0/0) in a Manual operating mode
Path tolerance, 214 8 - Tolerance programmed with Cycle 32 or MP 1096
Active datum shift, 220 2 1 in X axis
2Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
85th axis
9 W axis
Traverse range, 230 2 1 to 9 Negative software limit switch in axes 1 to 9
3 1 to 9 Positive software limit switch in axes 1 to 9
Nominal position in the REF
system, 240
1 1 in X axis
2Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
85th axis
9 W axis
Current position in the active
coordinate system, 270
1 1 in X axis
2Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
Group name, ID no. Number Index Meaning
