HEIDENHAIN iTNC 530 369

9.11 Preassigned Q parameters

Workpiece status Parameter value

Good Q180

Rework Q181

Scrap Q182

Measured deviation with Cycle 440 Parameter value

in X axis Q185

Y axis Q186

Z axis Q187

Marker for cycles Q188

Tool measurement with the BLUM laser Parameter value

Reserved Q190

Reserved Q191

Reserved Q192

Reserved Q193

Reserved for internal use Parameter value

Marker for cycles Q195

Marker for cycles Q196

Marker for cycles (machining patterns) Q197

Number of the last active measuring cycle Q198

Status of tool measurement with TT Parameter value

Tool within tolerance Q199 = 0.0

Tool is worn (LTOL/RTOL is exceeded) Q199 = 1.0

Tool is broken (LBREAK/RBREAK is

exceeded)

Q199 = 2.0
