HEIDENHAIN iTNC 530 533
12.7 Three-dimensional tool compensation (software option 2)
Example: Block format with surface normals without tool
orientation
Example: Block format with surface normals and tool orientation
LN X+31.737 Y+21.954 Z+33.165 NX+0.2637581 NY+0.0078922
NZ–0.8764339 F1000 M128
LN X+31.737 Y+21.954 Z+33.165 NX+0.2637581 NY+0.0078922
NZ–0.8764339 TX+0.0078922 TY–0.8764339 TZ+0.2590319 F1000
M128
LN: Straight line with 3-D compensation
X, Y, Z: Compensated coordinates of the straight-line end point
NX, NY, NZ: Components of the surface-normal vector
TX, TY, TZ: Components of the normalized vector for workpiece
orientation
F: Feed rate
M: Miscellaneous function
