552 Programming: Pallet Management
13.2 Pallet operation with tool-oriented machining
With the arrow keys and the ENT key, select the position that you wish
to confirm. Then press the ALL VALUES soft key so that the TNC
saves the respective coordinates of all active axes in the pallet table.
With the PRESENT VALUE soft key, the TNC saves the coordinates of
the axis on which the highlight in the pallet table is presently located.
SP-X, SP-Y, SP-Z (entry optional, other axes also possible):
Safety positions can be entered for the axes. These positions can be
read with SYSREAD FN18 ID510 NR 6 from NC macros. SYSREAD
FN18 ID510 NR 5 can be used to determine if a value was
programmed in the column. The positions entered are only
approached if these values are read and correspondingly
programmed in the NC macros.
CTID (entered by the TNC):
The context ID number is assigned by the TNC and contains
instructions about the machining progress. Machining cannot be
resumed if the entry is deleted or changed.
FIXTURE
In this column you can enter a fixture archive (ZIP file), that the TNC
is to automatically activate during machining of the pallet table. You
have to use the fixture management to archive fixture archives (see
"Managing fixtures" on page 419)
If you have not defined a pallet before an NC program, the
programmed coordinates are then referenced to the
machine datum. If you do not define an entry, the datum
that was set manually remains active.
Editing function in table mode Soft key
Select beginning of table
Select end of table
Select previous page in table
Select next page in table
Insert as last line in the table
Delete the last line in the table
Go to beginning of next line
Add the number of lines that can be entered at
the end of the table
Edit the table format
