554 Programming: Pallet Management

13.2 Pallet operation with tool-oriented machining

Delete fixture

Delete workpiece

Delete buffer memory contents

Tool-optimized machining

Workpiece-optimized machining

Connect or separate the types of machining

Mark level as being empty

Mark level as being unmachined

Editing function in entry-form mode Soft key
