18.1 General user parameters
Configuring tool table
(To omit from the
table: enter 0); Column
number in the tool
table for
MP7266.20
Tolerance for break detection in tool length – LBREAK.: 0 to 42; column width: 6 characters
MP7266.21
Tolerance for break detection in tool radius – RBREAK: 0 to 42; column width: 6 characters
MP7266.22
Tooth length (Cycle 22) – LCUTS: 0 to 42; column width: 11 characters
MP7266.23
Maximum plunge angle (Cycle 22) – ANGLE: 0 to 42; column width: 7 characters
MP7266.24
Tool type –TYP: 0 to 42; column width: 5 characters
MP7266.25
Tool material – TMAT: 0 to 42; column width: 16 characters
MP7266.26
Cutting data table – CDT: 0 to 42; column width: 16 characters
MP7266.27
PLC value – PLC-VAL: 0 to 42; column width: 11 characters
MP7266.28
Center misalignment in reference axis – CAL-OFF1: 0 to 42; column width: 11 characters
MP7266.29
Center misalignment in minor axis – CAL-OFF2: 0 to 42; column width: 11 characters
MP7266.30
Spindle angle for calibration – CALL-ANG: 0 to 42; column width: 11 characters
MP7266.31
Tool type for the pocket table – PTYP: 0 to 42; column width: 2 characters
MP7266.32
Limitation of spindle speed – NMAX: 0 to 42; Column width: 6 characters
MP7266.33
Retraction at NC stop – LIFTOFF: 0 to 42; column width is 1 character
MP7266.34
Machine-dependent function – P1: 0 to 42; column width: 10 characters
MP7266.35
Machine-dependent function – P2: 0 to 42; column width: 10 characters
MP7266.36
Machine-dependent function – P3: 0 to 42
; column width: 10 characters
MP7266.37
Tool-specific kinematics description – KINEMATIC: 0 to 42; column width: 16 characters
MP7266.38
Point angle T_ANGLE: 0 to 42; column width: 9 characters
MP7266.39
Thread pitch – PITCH: 0 to 42; column width: 10 characters
MP7266.40
Adaptive feed control – AFC: 0 to 42; column width: 10 characters
MP7266.41
Tolerance for wear detection in tool radius 2 – R2TOL: 0 to 42; column width: 6 characters
MP7266.42
Name of the compensation-value table for 3-D tool radius compensation depending on the tool's
contact angle
MP7266.43
Date/Time of the last tool call
TNC displays, TNC editor
