Technical data
44 1.10 GB (2019/02/28)
Load-driving capability
250mA (nominal), short circuit proof = maximum load across all outputs
Protection class
I; Class 2 peripheral devices may be connected
Label roll diameter
Standard: 300mm • 12"
Optional: 400 / 500 / 600mm • 16 / 20 / 23.6"; 600mm only with motorised winder)
Core diameter
Standard: 76mm • 3"
Winding diameter for mechanical rewinder
210mm / 290mm • 8.3 / 11.4"
Winding diameter for motorised rewinder
300mm / 400mm • 12" / 16"
Device widths / Max. label width / Max backing paper width
8 / 80mm / 82mm • 8 / 3.15" / 3.23"
16 / 160mm / 164mm • 16 / 6.3" / 6.45"
24 / 240mm / 246mm • 24 / 9.45" / 9.69"
32 / 320mm / 328mm • 32 / 12.6" / 12.91"
(See the type plate of the basic unit.)
Label length
5 – 800mm • 0.2 – 31.5"
