Documentation HERMA 500
1.10 GB (2019/02/28) 45
Distance between labels
2 – 3mm • 0.08 – 0.11"
Design variants
For right-handed and left-handed operation, arranged vertically (V) or horizontally (H).
(See the type plate of the basic unit / the component in question.)
Dimensions
Customer specific
Transport class
2M2 in accordance with DIN EN (IEC) 60721-3-2.
SlimLine winder system
Max. roll width for roll diameter of
400mm: 320mm • 16": 12.6"
500mm: 200mm • 20": 7.8"
600mm: 160mm • 23.6": 6.3"
Max. unrolling speed for core diameter of
3" : 120m/min • 394ft/min
6" : 150m/min • 492ft/min
You can find further data on the nameplate on the applicator.
The circuit board and the power supply unit are CE compliant.
Under extreme application conditions, the ranges specified here may not
exactly correspond to the necessary limits. If overloaded, the applicator
may shut down automatically.
