Global Masking Shape
The Mask Select parameter lets you choose a mask to frame or overlay a composite image. You can choose to apply a
mask to an image when you don't want an entire image to be seen or you want to transition from an image to black or a
solid color without fading intensity.
Mask Shapes
The graphics engine currently provides 30 mask shapes including circular, rectangular, and oval masks that close from
inside out or outside in. Checker Board, Radial Wipes, and Multi-panel options are also included with variations.
Default DMX Value = 0 Round “iris” closes from outside in.
DMX values 0-127 (0-50%) are reserved for static mask shapes.
Values of 128-255 (51-100%) are reserved for strobing Mask shapes.
Values not yet implemented default to 128.
DMX Value
Strobe DMX Value
Mask Shapes
0
128
Round iris closing from outside in
1
129
Round iris closing from inside out
2
130
Rectangle closing from outside in
3
131
Rectangle closing from inside out
4
132
Checkerboard, variation 1
5
133
Checkerboard, variation 2
6
134
Radial wipe, variation 1
7
135
Radial wipe, variation 2
8
136
Radial wipe, variation 3
9
137
Radial wipe, variation 4
10
138
Triangles, variation 1
11
139
Triangles, variation 2
12
140
Rectangular wrap
13
141
Tiles closing in
14
142
Horizontal doors, closing
15
143
Horizontal doors closing from opposing sides
16
144
Vertical doors closing from outside in
17
145
Vertical wipe closing from inside out
18
146
Rectangular tiles closing from inside out 1
19
147
Rectangular tiles closing from inside out 2
20
148
Vertical panels closing from outside in 1
21
149
Vertical panels closing from outside in 2
22
150
Vertical diamonds 1
23
151
Vertical diamonds 2
24
152
Horizontal diamonds 1
25
153
Horizontal diamonds 2
26
154
Pinwheel
27
155
Oval Iris closing from outside in
28
156
Oval Iris closing from inside out
29
157
Oscillating iris closing from outside in
30
158
Animated dynamic Iris
