High End Systems MMS100 - Pan and Tilt Motion Function

Pan and Tilt Motion Function
The MMS100 Pan and Tilt system allows the optical grade mirror to reposition the image output in a wide range of motion.
Pan Function
• Allows 196 degrees of rotation.
• Allows for 16 bit position accuracy
• Built in closed loop feedback for added precision (capable of being defeated)
Tilt Function
• Allows 51 degrees of rotation, equaling 102 degrees of image movement.
• Allows for 16 bit position accuracy
• Built in closed loop feedback for added precision (capable of being defeated)
Note:
The MMS100 fixture use optical encoders for pan and tilt to correct the mirror position if the mirror is held or
jarred from its programmed position. If a physical obstruction prevents the mirror from correcting its position,
this correction feature will time-out to prevent other damage. To reset the position correction, remove the
obstruction and home the fixture to return to normal operation.
