High End Systems MMS100 - MMS100 Technical Protocols and Specifications; MMS100 Protocol Reference

MMS100 Protocol
(version 1.1 JM 01/01/15)
Reference the sections below for DMX channel assignments. (Click Section Title to expand or collapse the section)
Motion Protocol
Motion Protocol
DMX Channel
Name
Note
Default
Range
Action
1 + 2
Pan Coarse
16 bit Channel
32768
0 thru 65535
Pan Movement
Pan Fine
3 + 4
Tilt Coarse
16 bit Channel
32768
0 thru 65535
Tilt Movement
Tilt Fine
5
mSpeed
0
0 thru 255
mSpeed Control Values
6
control trigger
127
0
0 - Triggers Control Channels
1-127
Fine Correction OFF
128-255
Fine Correction ON
7
control
0
0 thru 3
Safe
4 thru 7
pan and tilt mspeed off
8 thru 27
(reserved)
Hold 5 - Note 6
28 thru 31
Display Off
Hold 5 - Note 6
32 thru 35
Display Dim
Hold 5 - Note 6
36 thru 39
Display Bright
40 thru 43
Display Preview
44 thru 63
(reserved)
Hold 20 - Note 6
64 thru 67
Home All
68 thru 79
(reserved)
Hold 80 - Note 6
80 thru 83
Shutdown
Hold 80 - Note 6
84 thru 87
Graphics System Reset
88 thru 255
(reserved)
Global Protocol
Graphics Server Global Control
Start
Ch(+)
DMX
Channel
Name
Note
Default
Range
Action
8
1
Global Intensity
255
0 thru
255
closed to open
9
2
Effect 1
Indexed. Note
7
0
0 thru
255
10
3
Effect 1 Modifier 1
0
0 thru
255
11
4
Effect 1 Modifier 2
0
0 thru
255
12
5
Effect 1 Modifier 3
0
0 thru
255
13
6
Effect 2
Indexed. Note
7
0
0 thru
255
14
7
Effect 2 Modifier 1
0
0 thru
255
15
8
Effect 2 Modifier 2
0
0 thru
255
16
9
Effect 2 Modifier 3
0
0 thru
255
17
10
Effect 3
Indexed. Note
7
0
0 thru
255
18
11
Effect 3 Modifier 1
0
0 thru
255
19
12
Effect 3 Modifier 2
0
0 thru
255
20
13
Effect 3 Modifier 3
0
0 thru
255
21
14
Effect 4
Indexed. Note
7
0
0 thru
255
